3.5 System Information Setup
3.5.1 Quick Start up Software Version Information
Table 2-1. Quick Start up Software Version Information
Command Details
show hardware Allows the user to see the HW & SW version
the device contains
System Description - switch's model name
show version Allows the user to see Serial Number, Part
Number, and Model name
See SW loader, bootrom and operation
version
See HW version
3.5.2 Quick Start up Physical Port Data
Table 2-2. Quick Start up Physical Port
Command Details
show Interface status { <slot/port> |
all}
Displays the Ports slot/port
Type - Indicates if the port is a special type of
port
Admin Mode - Selects the Port Control
Administration State
Physical Mode - Selects the desired port
speed and duplex mode
Physical Status - Indicates the port speed and
duplex mode
Link Status - Indicates whether the link is up or
down
Link Trap - Determines whether or not to send
a trap when link status changes
LACP Mode - Displays whether LACP is
enabled or disabled on this port
Flow Mode - Indicates the status of flow control
on this port
Cap. Status - Indicates the port capabilities
during auto-negotiation
3.5.3 Quick Start up User Account Management
Table 2-3. Quick Start up User Account Management
Command Details
show users Displays all users that are allowed to access
the switch
User Access Mode - Shows whether the user
is able to chan
g
e
p
arameters on the switch
