Intf: Displays interface number.
Mode: Displays status of storm control multicast.
Level: Displays level for storm control multicast
Rate: Displays rate for storm control multicast.
This command is used to display unicast storm control information
Syntax
show storm-control unicast
Default Setting
None
Command Mode
Privileged Exec
Display Message
Intf: Displays interface number.
Mode: Displays status of storm control unicast.
Level: Displays level for storm control unicast
Rate: Displays rate for storm control unicast.
7.2.11.2 storm-control broadcast
This command enables broadcast storm recovery mode on the selected interface. If the mode is enabled,
broadcast storm recovery with high threshold is implemented. The threshold implementation follows a
percentage pattern. If the broadcast traffic on any Ethernet port exceeds the high threshold percentage
(as represented in “Broadcast Storm Recovery Thresholds” table) of the link speed, the switch discards
the broadcasts traffic until the broadcast traffic returns to the threshold percentage or less. The full
implementation is depicted in the “Broadcast Storm Recovery Thresholds” table.
Syntax
storm-control broadcast
no storm-control broadcast
no - This command disables broadcast storm recovery mode on the selected interface. The threshold
implementation follows a percentage pattern. If the broadcast traffic on any Ethernet port exceeds the
high threshold percentage (as represented in “Broadcast Storm Recovery Thresholds” table) of the
link speed, the switch discards the broadcasts traffic until the broadcast traffic returns to the threshold
percentage or less. The full implementation is depicted in the “Broadcast Storm Recovery
Thresholds” table.
