- 101 -
Syntax
show ip igmp snooping querier
Command Mode
Privilege Exec
Display Information
IGMP Snooping Querier Mode: Administrative mode for IGMP Snooping. The default is disable.
Querier Address: Specify the Snooping Querier Address to be used as source address in periodic
IGMP queries. This address is used when no address is configured on the VLAN on which query is
being sent.
IGMP Version: Specify the IGMP protocol version used in periodic IGMP queries.
Querier Query Interval: Specify the time interval in seconds between periodic queries sent by the
snooping querier. The Query Interval must be a value in the range of 1 and 1800. The default value is
60.
Querier Expiry Interval: Specify the time interval in seconds after which the last querier information
is removed. The Querier Expiry Interval must be a value in the range of 60 and 300. The default value
is 60.
7.2.7.10 show ip igmp snooping querier vlan
This command display IGMP snooping querier vlan information on the system.
Syntax
show ip igmp snooping querier vlan <1-3965>
<vlanid> - VLAN ID (Range: 1 - 3965).
Command Mode
Privilege Exec
Display Information
IGMP Snooping Querier Vlan Mode: Display the administrative mode for IGMP Snooping for the
switch.
Querier Election Participation Mode: Displays the querier election participate mode on the VLAN.
When this mode is disabled, up on seeing a query of the same version in the vlan, the snooping
querier move to non querier state. Only when this mode is enabled, the snooping querier will
participate in querier election where in the least ip address will win the querier election and operates
as the querier in that VLAN. The other querier moves to non-querier state.
Querier Vlan Address: Displays the Snooping Querier Address to be used as source address in
periodic IGMP queries sent on the specified VLAN.
Operational State: Specifies the operational state of the IGMP Snooping Querier on a VLAN.
