User manual

Problem Possible cause and solution
Dull, discoloured or chipped
tableware.
• Make sure that only dishwasher-safe items are washed
in the appliance.
• Load and unload the basket carefully. Refer to basket
loading leaflet.
• Place delicate items in the upper basket.
• For washing delicate items and glassware, select the
dedicated programme. Refer to "Programmes".
Refer to "Before first use",
"Daily use" or "Hints and
tips" for other possible causes.
TECHNICAL INFORMATION
Dimensions Width / height / depth (mm) 596 / 818 - 898 / 550
Electrical connection
1)
Voltage (V) 200 - 240
Frequency (Hz) 50 / 60
Water supply pressure bar (minimum and maximum) 0.5 - 8
MPa (minimum and maximum) 0.05 - 0.8
Water supply
Cold water or hot water
2)
max 60 °C
Capacity Place settings 15
Power consumption Left-on mode (W) 5.0
Off-mode (W) 0.10
1)
Refer to the rating plate for other values.
2)
If the hot water comes from alternative source of energy (e.g. solar panels), use the hot water supply to de‐
crease energy consumption.
GUARANTEE CONDITIONS
2 year warranty covering household
appliances.
We would like to congratulate you on your
purchase of a FORS product. You have
made a good choice and selected a
product of extremely high quality, which
also rates excellently in the area of
ecobalance.
We provide a two-year warranty covering
the operating ability and operational safety
of this appliance insofar as we guarantee
that the appliance is free from material
defects and manufacturing defects. During
the two-year warranty period, from the day
on which the appliance is first installed
onwards, from 01.01.2004 at the earliest,
we will replace faulty parts free of charge
to the owner in line with the following
provisions. The new warranty period of
two years applies only to those appliances
which come with this warranty brochure.
This warranty only applies however if the
inspection carried out by FORS AG
locates a defect that is without doubt
covered by these warranty provisions.
23
