Specification Sheet

11/2020
Specifications
Speed: Up to 17,000 sheets per hour – based on 11” (279mm) Z-Fold
Hopper Capacity: Up to 500 sheets 20# (75 gsm)
Pre-Set Folds: Pre-programmed for C,V,Z, Gate, Fold Out and Double Parallel
Pre-Set Paper Sizes: 11”, 14”, 17”, A5, A4, A3, B6, B5, B4
Custom Folds: Up to 36
Paper Size: Min: 3.5” W x 5” L (88.9 W x 127 L mm)
Max: 12.25” W x 18” L (311 W x 457 L mm)
Dimensions: Closed: 33” L x 20” W x 19” H (84 L x 51 W x 48 H cm)
Fully Extended: 60” L x 20” W x 19” H (152 L x 51 W x 48 H cm)
Weight: 73 lbs (33kg)
Power: 110-240VAC 50/60 Hz
Safety Certications: UL & CE approved
Formax - New Hampshire, USA
www.formax.com
Local Dealer:
Fast!: Large jobs are processed quickly at speeds of up to 17,000 pieces per hour
Color Touchscreen: The large full-color touchscreen control panel allows anyone to walk up and start
folding in seconds
Drop-In Feed System: Three-roller drop-in feed system produces dependable feeding of forms with no
fanning required
AutoStack
TM
Stacker Wheels: Fully-automated stacker wheels eliminate moving them by hand when
switching paper sizes and fold types
Telescoping Conveyor System: Conveyor can be set between 14” (356mm) and 36” (915mm) in length
and holds up to 500 folded pieces
Noise Reduction: Fold plates are enclosed and insulated to reduce operating noise
6-Digit Resettable & 8-Digit Life Counters: Provides maximum audit control
AutoBatch
TM
: Programmable to process pre-set number of sheets into sets with a delay
Six Standard Folds in Common Paper Sizes: Pre-programmed for 6 popular fold types in letter, legal and
ledger paper sizes equalling 18 preset fold settings
Custom Folds: Up to 36 custom folds can be programmed and stored into memory
Dedicated Multi-Sheet Feeder: Allows for up to 4 stapled or unstapled sheets to be folded at once, with
the ability to select standard or custom folds in letter and legal paper sizes
Standard Fold Settings Modication: Even the six standard fold types can be modied individually for
each paper size for maximum exibility and customization
Cross-Folding: A guide is included for two pass operation
Pressure Seal Solutions • Mailing Solutions • Data Destruction Solutions • Digital Print & Finishing Solutions
FD 38Xi in-line with optional V-Stack36i
Vertical Stacker, stand and cabinet
Options
Locking Cabinet: Fully enclosed for storage
V-Stack36i Vertical Stacker: Aligns with FD 38Xi outfeed and vertically stacks up to 22” of folded
documents, making them easier to unload for further processing
Easy-Off Feed Wheel Shaft: Feed wheels can be changed without removing side covers
Seven Point Fold Stops: Fold plates utilize seven point fold stops for crisp, accurate folds of large paper
sizes at high speeds
Removable Roller Cover: Easily removed for improved access to fold rollers and exit area
Technical Features
AutoStack
TM
Stacker Wheels
Removable Feed Wheels
Folding Features
Operating Features
Large color touchscreen
Optional Multi-Sheet Feeder
