Recommended Headlamp Leveling Switch Positions

Switch positionLoad in luggage

compartment

Load

Second row seatsFront seats

0--1-2

1.5-32

2.5

Max

3.5

Max

-1

See Vehicle Identification Plate (page 186).

DIRECTION INDICATORS

Push the lever up or down to use the

direction indicators.

Note: Tap the lever up or down to make the

direction indicators flash three times to

indicate a lane change.

INTERIOR LAMPS

Courtesy Lamp

OffA

Door contactB

OnC

If you set the switch to position B, the

courtesy lamp will illuminate when you

unlock or open a door or the liftgate. If you

leave a door open with the ignition

switched off, the courtesy lamp will go off

automatically after some time to prevent

your vehicle battery from losing charge. To

switch it back on, switch the ignition on for

a short time.

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Lighting
