Capacity in gallons

(liters)

ItemVariant

0.6 (2.5)Windshield and rear

window washer

system

All

approximately 1.4

(6.3)

Engine cooling

system

1.0L EcoBoost

approximately 1.2

(5.5)

Engine cooling

system

Vehicles with a gasoline engine except

1.0L EcoBoost

approximately 1.3 (6)Engine cooling

system

Vehicles with a diesel engine

10.6 (48)Fuel tankVehicles with a gasoline engine

10.3 (47)Fuel tankVehicles with a diesel engine

0.9 (4.1)Engine lubrication

system - including

the oil filter

1.0L EcoBoost

0.9 (4.0)Engine lubrication

system - excluding

the oil filter

1.0L EcoBoost

0.9 (4.1)Engine lubrication

system - including

the oil filter

1.4L Duratec-16V

0.8 (3.8)Engine lubrication

system - excluding

the oil filter

1.4L Duratec-16V

0.9 (4.1)Engine lubrication

system - including

the oil filter

1.6L Duratec-16V Ti-VCT

0.8 (3.8)Engine lubrication

system - excluding

the oil filter

1.6L Duratec-16V Ti-VCT

0.8 (3.8)Engine lubrication

system - including

the oil filter

1.5L Duratorq-TDCi

170

B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013

Maintenance
