Note: LED lamps are not serviceable.
TECHNICAL SPECIFICATIONS
Vehicle Fluids
Note: Use fluids which meet the specifications or requirements defined. Use of other fluids
may lead to damage which is not covered by your warranty.
Recommended fluid
Viscosity
Grade
SpecificationItem
Castrol or Ford Engine
Oil
5W-20WSS-M2C948-B
Engine oil - gasoline
engines only
Castrol or Ford Engine
Oil
5W-30WSS-M2C913-C
Alternative engine oil - all
gasoline engines except
1.0L EcoBoost
Castrol or Ford Engine
Oil
5W-30WSS-M2C913-CEngine oil - diesel engines
Motorcraft SuperPlus
Antifreeze
-WSS-M97B44-DAntifreeze
Motorcraft or Ford DOT
4 LV High Performance
Brake Fluid
-WSS-M6C65-A2Brake fluid
Your engine has been designed to be used with Castrol and Ford Engine Oil, which gives
a fuel economy benefit while maintaining the durability of your engine.
Adding oil: If you are unable to find an oil that meets the specification defined by
WSS-M2C913-C or WSS-M2C948-B (gasoline engines only), you must use SAE 5W-30
that meets the specification defined by ACEA A5/B5.
Using oils other than the one specified can result in longer engine cranking periods, reduced
engine performance, reduced fuel economy and increased emission levels.
Castrol engine oil recommended.
169
B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013
