Luggage Compartment Lamp,
Footwell Lamp and Liftgate Lamp
1. Carefully prize out the lamp.
2. Remove the bulb.
BULB SPECIFICATION CHART
Power (watt)SpecificationLamp
21PY21WFront direction indicator
55H1Headlamp high beam - high series
55H15Headlamp high beam - low series
55H7Headlamp low beam
55H8Front fog lamp
5W5WSide lamp - low series
5WY5WSide repeater
5W5WApproach lamp
21PY21WRear direction indicator
21/5P21/5WBrake and tail lamp
21H21WRear fog lamp
21P21WReversing lamp
5W5WLicence plate lamp
5W5WLuggage compartment lamp
