Rear Lamps
Direction Indicator, Tail and Brake
Lamp
1. Remove the trim panel.
2. Disconnect the electrical connector.
3. Remove the wing nut.
4. Remove the lamp.
5. Remove the bulb holder.
6. Gently press the bulb into the bulb
holder, turn it counterclockwise and
remove it.
A. Tail and brake lamp
B. Direction indicator
Reversing Lamp and Fog Lamp
1. Open the liftgate.
2. Remove the trim panel.
165
B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013
Maintenance
