2. Remove the cover.
3. Disconnect the electrical connector.
4. Release the clip and remove the bulb.
Note: Do not touch the glass of the bulb.
Headlamp Low Beam
1. Remove the headlamp. See
Removing a Headlamp (page 161).
2. Remove the cover.
3. Turn the bulb holder counterclockwise
and remove it.
4. Remove the bulb.
Note: Do not touch the glass of the bulb.
Side Lamp
1. Remove the headlamp. See
Removing a Headlamp (page 161).
2. Remove the cover.
3. Remove the bulb holder.
4. Remove the bulb.
Side Repeater
1. Carefully remove the side repeater.
163
B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013
