Note: When fitting the headlamp, make
sure that you fully engage the headlamp in
the lower fixing point.
CHANGING A BULB
WARNINGS
Switch the lamps and the ignition off.
Let the bulb cool down before
removing it.
Do not touch the glass of the bulb.
Note: Only fit bulbs of the correct
specification.
Note: The following instructions describe
how to remove the bulbs. Fit replacements
in the reverse order unless otherwise stated.
Headlamp
Note: Remove the covers to gain access to
the bulbs.
Headlamp high beamA
Headlamp low beamB
Direction indicatorC
Direction Indicator
1. Remove the headlamp. See
Removing a Headlamp (page 161).
2. Turn the bulb holder counterclockwise
and remove it.
3. Gently press the bulb into the bulb
holder, turn it counterclockwise and
remove it.
Headlamp High Beam
1. Remove the headlamp. See
Removing a Headlamp (page 161).
162
B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013
