Circuits protectedFuse ratingFuse
Navigation
Instrument cluster7.5 A22
Multi functional display
7.5 A23
Clock
Internal scanner
Heating vents
Air conditioning panel
SYNC module10 A24
Not used-25
Front wiper left-hand side30 A26
Front wiper right-hand side30 A27
Voltage quality module30 A28
Rear power point20 A29
Cigar lighter
20 A30
Auxiliary power point
Not used-31
Not used-32
Not used-33
Keyless entry20 A34
Keyless entry20 A35
Not used-36
Ignition switch15 A37
Not used-38
Not used-39
Not used-40
Not used-41
Rear view camera7.5 A42
Active city stop module10 A43
149
B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013
Fuses
