Circuits protectedFuse ratingFuse
Heated windshield
Dome lamp
Interior mirror
Stop lamps10 A2
Reversing lamp3 A3
Headlamp leveling7.5 A4
Not used-5
Rear window wiper15 A6
Washer pump15 A7
Not used-8
Passenger heated seat15 A9
Driver heated seat15 A10
Not used-11
Airbag module10 A12
Ignition
10 A13
Electric power assisted
steering
Instrument cluster
Passive anti-theft system
Anti-lock brake system
Powertrain control module
7.5 A14 Fuel pump
Transmission selector lever
Audio system
7.5 A15
Instrument cluster
Heated windshield7.5 A16
Not used-17
Not used-18
Data link connector10 A19
Trailer module20 A20
Audio system15 A21
148
B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013
Fuses
