Circuits protectedFuse ratingFuse
Front wiper, left-hand side30 A26
Front wiper, right-hand side30 A27
Voltage quality module30 A28
Rear power point20 A29
Cigar lighter, front power
point
20 A30
Not used-31
Not used-32
Not used-33
Keyless entry20 A34
Keyless entry20 A35
Data link connector10 A36
Ignition switch15 A37
Not used-38
Not used-39
Not used-40
Not used-41
Rear view camera7.5 A42
Active city stop module10 A43
Not used-44
Not used-45
Not used-46
Not used-47
Not used-48
Not used-49
142
B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013
Fuses
