Circuits protectedFuse ratingFuse
Ignition, electric power
assisted steering, instrument
cluster, passive anti-theft
system, anti-lock braking
system
10 A13
Powertrain control module,
transmission selector lever,
fuel pump
7.5 A14
Audio system, instrument
cluster
7.5 A15
Heated windshield7.5 A16
Not used-17
Not used-18
Data link connector15 A19
Multi function display, clock,
internal scanner, heating
vents, air conditioning panel
20 A20
Audio system, navigation,
bluetooth
15 A21
Instrument cluster7.5 A22
Trailer module7.5 A23
Sync module antenna7.5 A24
Not used-25
Front wiper, left-hand side30 A26
Front wiper, right-hand side30 A27
Circuits switchedRelay
IgnitionR1
139
B-MAX (CB2) Vehicles Built From: 25-06-2012, Vehicles Built Up To: 31-12-2013
Fuses
