Note: Not all vehicles are suitable or
approved to have tow bars fitted. See an
authorized dealer for further information.
Trailer Lighting
The electrical system on your vehicle is not
suitable for towing trailers with LED lamps.
TOW BALL
WARNINGS
When not in use, always transport
the tow ball arm securely fastened
in the luggage compartment.
Take special care when fitting the
tow ball arm as the safety of your
vehicle and the trailer depends on
this.
Do not use any tools for mounting or
dismounting the tow ball arm.
Do not modify the trailer coupling.
Do not disassemble or repair the tow
ball arm.
A 13-pin trailer socket and the tow ball arm
seat are provided under the rear bumper.
Turn the trailer socket down through 90
degrees until it engages in the end position.
Unlocking the Tow Ball Arm
Mechanism
1. Remove the protecting cap.
2. Insert the key and turn it clockwise to
unlock.
3. Hold the tow ball arm. Pull the
handwheel out and turn it clockwise
until it clicks.
Note: The red mark on the handwheel must
align with the green mark on the tow ball.
4. Release the handwheel. The tow ball
arm is unlocked.
Inserting the Tow Ball Arm
WARNING
The tow ball arm may only be
inserted when completely unlocked.
125
