User Manual

3
EN
FORCE RC
®
FCES13000 REPLACEMENT TRANSMITTER MANUAL
3CH/ BIND BUTTON
This button serves as
both a bind button and a
channel 3 button.
STEERING WHEEL
Turn the wheel on the
transmitter to turn the
wheels on the vehicle..
THROTTLE TRIGGER
Controls power to motor for forward
or reverse (see TH. REV switch).
Stop
Reverse
(when TH.
REV switch
on N).
Forward
(when TH.
REV switch on N).
LIMITED WARRANTY
DATE OF PURCHASE LIMITED WARRANTY
Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product purchased (the "Product") will be free from defects in materials
and workmanship at the date of purchase.
What is Not Covered - This warranty is not transferable and does not cover (i) cosmetic damage, (ii) damage due to acts of God, accident, misuse, abuse,
negligence, commercial use, or due to improper use, installation, operation or maintenance, (iii) modifi cation of or to any part of the Product, (iv) attempted service by
anyone other than a Horizon Hobby authorized service center, (v) Product not purchased from an authorized Horizon dealer, (vi) Product not compliant with applicable
technical regulations, or (vii) use that violates any applicable laws, rules, or regulations.
OTHER THAN THE EXPRESS WARRANTY ABOVE, HORIZON MAKES NO OTHER WARRANTY OR REPRESENTATION, AND HEREBY DISCLAIMS ANY AND ALL IMPLIED
WARRANTIES, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. THE PURCHASER ACKNOWLEDGES THAT THEY ALONE HAVE DETERMINED THAT THE PRODUCT WILL SUITABLY MEET THE REQUIREMENTS OF THE
PURCHASER’S INTENDED USE.
Purchaser’s Remedy - Horizon’s sole obligation and purchaser’s sole and exclusive remedy shall be that Horizon will, at its option, either (i) service, or (ii) replace,
any Product determined by Horizon to be defective. Horizon reserves the right to inspect any and all Product(s) involved in a warranty claim. Service or replacement
decisions are at the sole discretion of Horizon. Proof of purchase is required for all warranty claims. SERVICE OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE PURCHASER’S SOLE AND EXCLUSIVE REMEDY.
Limitation of Liability - HORIZON SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSS OF PROFITS OR
PRODUCTION OR COMMERCIAL LOSS IN ANY WAY, REGARDLESS OF WHETHER SUCH CLAIM IS BASED IN CONTRACT, WARRANTY, TORT, NEGLIGENCE, STRICT
LIABILITY OR ANY OTHER THEORY OF LIABILITY, EVEN IF HORIZON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Further, in no event shall the
liability of Horizon exceed the individual price of the Product on which liability is asserted. As Horizon has no control over use, setup, fi nal assembly, modifi cation or
misuse, no liability shall be assumed nor accepted for any resulting damage or injury. By the act of use, setup or assembly, the user accepts all resulting liability. If
you as the purchaser or user are not prepared to accept the liability associated with the use of the Product, purchaser is advised to return the Product immediately in
new and unused condition to the place of purchase.
Law - These terms are governed by Illinois law (without regard to confl ict of law principals). This warranty gives you specifi c legal rights, and you may also have
other rights which vary from state to state. Horizon reserves the right to change or modify this warranty at any time without notice.
WARRANTY SERVICES
Questions, Assistance, and Services - Your local hobby store and/or place of purchase cannot provide warranty support or service. Once assembly, setup or use of
the Product has been started, you must contact your local distributor or Horizon directly. This will enable Horizon to better answer your questions and service you
in the event that you may need any assistance. For questions or assistance, please visit our website at horizonhobby.com, submit an inquiry to productsupport@
horizonhobby.com or call the toll-free telephone number referenced in the Warranty and Service Contact Information section to speak with a Product Support
representative.
BINDING
Binding is the process of programming the
receiver to recognize the GUID (Globally
Unique Identifi er) code of a single specifi c
transmitter. The FCES13000 transmitter
and FCES13001 receiver are bound at the
factory. If you need to rebind, follow the
instructions below.
1. Hold the 3CH button, then turn on
the transmitter. A blue LED will
begin flashing and the transmitter
will begin beeping. Release the 3CH
button.
2. Power on the ESC. An LED on the receiver will flash slowly.
3. Press and hold the button on the receiver until the LED flashes several times and then
returns to a slow flash. Release the button after the LED returns to a slow flash.
4. Turn off the transmitter, then turn it back on again. The LED on the receiver should now
be steadily lit, which indicates binding is complete.
