Tempo Undercounter Ice Machine Bin 43
Evaporator Assembly
Reference # Description Part #
1 Gearmotor Assy 00957811
2 Main Housing with Front Seal and Screws 00957829
3 Screws, Main Housing 00957837
4 Auger with front seal 00957845
5 Ice Compression Nozzle Assy 01332972
6 Front Seal and O-Ring 00957860
7 Evaporator Assembly with Insulation 01157353
8 Housing, Bushing with Insulation 00957886
9 Hardware kit, Gearmotor (For serial numbers E01087 and above) 01048628
9 Hardware kit, Gearmotor (For serial numbers below E01087) 00957894
10 Reservoir and Float Complete Assy 01332980
11 Lid, Reservoir and O-Ring (does not include bolt) 01332998
12 Float Valve 01333004
13 “T” Fitting - 1/4" 502923
14 Tubing - 1/4" (sold in 12" increments) 502079
15 Retention clip 01277862
16 Water seal kit 01340801
