Operation and Service Manual

Tempo Undercounter Ice Machine Bin 41
Exterior
Reference Description Part #
1 Panel, access front 01305846
2 Panel, rear 01305853
3 Compressor 01305861
4 Condenser 01305879
5 Condenser, fan blade 01305887
6 Condenser, fan motor 01305895
7 Cover, with hook 01305903
8 Display assembly 01305911
9 Door assembly 01306133
9 Door assembly ADA 01305929
10 Drier 01305937
11 Valve, purge 01305945
12 Module, oat, evaporator 01250158
13 Door, gasket 01305952
14 Grill assembly, front-bottom 01305960
15 Heat exchanger assembly 01305978
16 Door, hinge assembly 01305986
16 Door, hinge assembly ADA 01306117
17 Door, hinge cover (2) 01305994
18 Ice scoop 01306000
19 Light, led strip and cover 01306018
20 Legs, levelers (4) 01306026
21 Main board assembly 01306034
Not shown Safeclean Plus 01147826
22 Switch, door 01306042
Not shown Power cord, ADA 01306059
23 Thermistor 01306067
24 Valve, reservoir inlet 01306075
Not shown Wire harness, control board 01306083
Not shown Sheet metal screw and clips (sold in sets of 20) 01306091
Not shown Everpure lter 00968107
Not shown Pump, drain 01306109
Not shown Power cord 01306125
Not shown Return packaging kit for ADA units 01308246
Not shown Return packaging kit 01308238
