Operation and Service Manual

4 Tempo Undercounter Ice Machine Bin
Specications
Dimensions
Width Depth Height* Unit Shipping Weight
UCD100A30-NF
UCD100A30-CF
14.96" (38.0 cm) 24.38" (61.9 cm) 34.12" to 35.12"
(86.7 cm to 89.2 cm)
101 lb (45.8 kg)
UCD100A30ADA-NF
UCD100A30ADA-CF
14.96" (38.0 cm) 24.38" (61.9 cm) 32.00" to 33.00"
(81.3 cm to 83.8 cm)
101 lb (45.8 kg)
* Leveling legs, adjustable up to 0.25" (6.4 mm).
Ambient Information
CAUTION!
This unit is for indoor use only. Designed for commercial use. Follett is not
able to provide in-house services for residential installations.
Maximum* Minimum*
Air Temperature
†
100 F (38 C) 50 F (10 C)
Water Temperature 90 F (32.2 C) 40 F (4.5 C)
Water Pressure 70 psi (483 kpa) 10 psi (69 kpa)
Relative Humidity 55% at 78 F (25.5 C)
* Use outside of these limitations is misuse and will void warranty.
†
Best performance is achieved between 80 F (27 C) and 50 F (10 C).
Plumbing
§ Water Inlet: 1/4" compression
§ 3/8" braided drain hose (8' (2.4 m) provided)
§ Water shut-off recommended within 5 ft (1.5 m) of dispenser
§ This equipment is to be installed with adequate backow protection to comply with applicable federal, state, and
local codes.
