Tempo Undercounter Ice Machine Bin 29
Refrigeration Schematic
LOW PRESSURE LIQUID
HIGH PRESSURE VAPOR
HIGH PRESSURE LIQUID LOW PRESSURE VAPOR
CAP TUBE
FILTER-DRIER
CONDENSER
COMPRESSOR
EVAPORATOR
