Installation Instructions for Remote Condenser

5
REMOTE CONDENSING UNIT
Electrical requirements
2.2
• Level unit
• Securely attach base of unit using holes found in base plate
• Required rack system capacity at 0 F (-18C) evaporator (EPR supplied by installer).
1010N: 7,700 Btu/hr (1940 kcal/hr)
1410N: 10,000 Btu/hr (2519 kcal/hr)
Condenser installation
2
Install condensing unit
2.1
CAUTION
• Electrical disconnects required within 10' (3 m) for all hard wired connections
• Install in accordance with NEC and local electrical codes
Horizon Elite 1010 series Horizon Elite 1410 series
Minimum circuit ampacity single phase – 10.7A
three phase – 9.9A
single phase – 19.3A (Tecumseh AWA9513ZXDPN)
single phase – 16.4A (Tecumseh
ASFS9516ZNAMC1)
three phase – 15A (Larkin)
Maximum overcurrent
protection
single phase – 15A
three phase – 15A
single phase – 30A (Tecumseh AWA9513ZXDPN)
single phase – 25A (Tecumseh
ASFS9516ZNAMC1)
three phase – 15A (Larkin LZT015M6CFIM)
three phase – 20A (Larkin LCH0015MCACZ)
Outdoor condensing unit
operating limits
(air temperature)
min –20 F (–29 C)
max 120 F (49 C)
min –20 F (–29 C)
max 120 F (49 C)
