Owners Manual

8 Undercounter Dispenser and Ice Machine 7UC100A/7UD100A
5. Connect water line. Recommended routing (Fig. 3) allows easy access
to water for cleaning and sanitizing procedure.
Fig. 3
6. If installing the optional internal water lter*, please complete the
steps shown in Cleaning and Sanitizing Procedure on page 11
before proceeding. If not, proceed to step 10.
* If your dispenser has the internal water lter option, the water lter must be
installed for the dispenser to operate. Because internal components will need to
be accessed for both procedures, Follett recommends installing the water lter
just prior to initial sanitizing.
7. Lift and remove the top panel, set aside (Fig. 4.1).
8. Remove two screws (Fig. 4.2) and remove left side panel.
9. Install lter as shown. Turn lter clockwise until it is fully seated
(Fig.4.3).
10. Connect power supply.
11. Sanitize the dispenser prior to use (see Cleaning and Sanitizing
Procedure on page 11).
Fig. 4
1
2
3
1/4" MPT
3' (91.4 cm)
Plug
Valve
