Owners Manual

Undercounter Dispenser and Ice Machine 7UC100A/7UD100A 33
Evaporator Assembly
Reference # Description Part #
1 Gearmotor Assembly 00957811
2 Main Housing with Front Seal and Screws 00957829
3 Screws, Main Housing 00957837
4 Auger with front seal (includes gearmotor hardware kit) 00957845
5 Ice Compression Nozzle Assy 00957852
6 Front Seal and O-Ring 00957860
7 Evaporator Assembly with Insulation 01157353
8 Housing, Bushing with Insulation 00957886
9 Hardware kit, Gearmotor (For serial numbers E01087 and above) 01048628
9 Hardware kit, Gearmotor (For serial numbers below E01087) 00957894
10 Reservoir and Float Complete Assy 00957902
11 Lid, Reservoir with Insulation and O-Ring (does not include bolt) 00957910
12 Float Valve 00957928
13 “T” Fitting - 1/4" 502923
14 Tubing - 1/4" 502079
15 Vent Tube Retainer (includes vent tube) 01278779
16 Seal kit (includes 2 ft of 1/4" tubing) 01348093
Miscellaneous
Reference # Description Part #
Not Shown Water lter cartridge, 5 micron 00968107
Not Shown Cleaning and sanitizing kit, single use 00979856
Not Shown SafeClean Plus liquid, case of 6 01149954
Not Shown SafeClean Plus liquid, case of 24 01149962
Not Shown IMS III sanitizer concentrate, 16 oz 00979674
