7 Series Bin Assembly
Reference # Description Part #
1 Ice Chute, Inside Thread
0
1238906
2 Ice Transport Tubing with Insulation 00957746
3 Switch, Shuttle 00957753
4 Lid, Bin Assy 01233808
5 Lid, Gasket, 7 Series 01233824
6 Auger, Dispense 00931113
7 Assembly, Motor Dispense 01233857
8 Cap and gasket 01233816
9 Bin assembly, 7 Series (does not include ice transport tube and insulation) 01233832
10 Coupling, transport tube 00998278
11 Flag, shuttle 00998286
12 Spring, wave 00998302
13 Bracket, shuttle support (Before serial number K46457) 00998260
13 Bracket, shuttle support (After serial number K46456) 00998336
14 Screws (2), self-tapping, #10 x 5/8 00998328
15 Screws (2), M3 x 12 Phillips pan head 00998294
