Undercounter Dispenser and Ice Machine 7UC100A/7UD100A 27
Exterior
Reference # Description Part #
1 Drain, Tray Assy 00957613
2 Panel, Front Assy - Includes Water Nozzle and Plug 00957621
3 Chute, Water (water option) 00957688
4 Panel, Top Left 00947010
5 Panel, Top Right 00947028
6 Panel, Top 00957654
7 Panel, Rear 00957662
8
Panel, Lower, 7UC100A Height: 12.0" (304.8 mm) 00932855
Panel, Lower, 7UD100A Height: 10.0" (254 mm) 00932863
9 Panel, Intake 00947119
Not Shown Cord, 115 VAC 00958058
Not Shown Packaging for Returns, Dispenser 00957993
Not Shown Covers, Agion, User Interface 00969030
10
Panel, Bottom Left/Right, 7UC100A 00967331
Panel, Bottom Left/Right, 7UD100A 00967356
11
Panel, Bottom Rear, 7UC100A 00967349
Panel, Bottom Rear, 7UC100A 00967364
Not Shown Fitting, Elbow - 1/4" FPT x 1/4" Tube 00974261
Not Shown Fitting, Elbow - 1/4" FPT x 3/8" Tube 00990796
Not Shown Drip Tray Drain Kit 00956375
