802.11n /13.5Mbps : EVM≦-5dB
802.11n /135Mbps : EVM≦-28dB
Receiver Sensitivity
(WiFi)
802.11b@8% PER
1Mbps
≦
-91dBm
2Mbps
≦
-89dBm
5.5Mbps
≦
-87dBm
11Mbps
≦
-85dBm Max input level
≥
-8
802.11g@10% PER
6Mbps ≦ -87dBm
9Mbps ≦ -86dBm
12Mbps ≦ -84dBm
18Mbps ≦ -82dBm
24Mbps ≦ -79dBm
36Mbps ≦ -75dBm
48Mbps ≦ -71dBm
54Mbps ≦ -70dBm Max input level≥-20
802.11n@10% PER
HT20_MCS 0 ≦-87dBm HT40_MCS 0≦-84
HT20_MCS 1 ≦-84dBm HT40_MCS 1≦-81
HT20_MCS 2 ≦-82dBm HT40_MCS 2≦-79
HT20_MCS 3 ≦-79dBm HT40_MCS 3≦-76
HT20_MCS 4 ≦-75dBm HT40_MCS 4≦-72
HT20_MCS 5 ≦-71dBm HT40_MCS 5≦-68
HT20_MCS 6 ≦-70dBm HT40_MCS 6≦-67
HT20_MCS 7 ≦-69dBm HT40_MCS 7≦-66
Max input level≥-20
Receiver Sensitivity
(BT)
-89dBm @ 1Mbps
-86dBm @ 2Mbps
-83dBm @ 3Mbps
Operating Channel
WiFi 2.4GHz:
11: (Ch. 1-11) – United States
BT 2.4GHz: Ch. 0 ~78
