User Manual

6223E-UUD
FN-LINK TECHNOLOGY LIMITED
8
Proprietary & Confidential Information
12 USB_DM I/O USB2.0 differential pair for WLAN And Bluetooth
13 USB_DP I/O USB2.0 differential pair for WLAN And Bluetooth
14 GND － Ground connections
15 3DD_SEL － Not connecting
16 WL_EN I WLAN enable
17 BT_EN I Bluetooth enable
18 NC I Not connecting
19 HOST_WAKE_WL I Host wake up WLAN device
20 WL_WAKE_HOST O WLAN device wake up host
