欧智通科技 Fn-Link 6223E-UUD WiFi Single-band 1X1 + Bluetooth v2.1+EDR/Bluetooth 3.0/3.0+HS/4.
6223E-UUD Revision History Version Date 1.0 2016-09-26 1.1 1.2 Description Draft Approved First release Colin Ming William Tan 2017-02-24 Interface modified.
6223E-UUD CONTENTS 1. Introduction..............................................................................................................................1 2. Features.................................................................................................................................... 2 3. General Specification............................................................................................................ 3 3.1 General Specification............................................
6223E-UUD 1. Introduction 6223E-UUD is a small size and low profile of WiFi + BT Combo module, board size is 12.2mm*13mm with module thickness of 1.7mm. It can be easily manufactured on SMT process and highly suitable for tablet PC, ultra book, mobile device and consumer products. It provides USB interface for WiFi and Bluetooth. The WiFi throughput can go up to 150Mbps in theory by using 1x1 802.11n SISO technology and Bluetooth can support BT2.1+EDR/BT3.0 and BT4.2.
6223E-UUD 2. Features Operate at ISM frequency bands (2.4GHz) USB for WiFi and Bluetooth IEEE standards support: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11d, IEEE 802.11e, IEEE 802.11h, IEEE 802.11i Fully Qualified for Bluetooth 2.1+EDR specification including both 2Mbps and 3Mbps modulation mode Fully qualified for Bluetooth 3.0 Fully qualified for Bluetooth 4.
223E-UUD 3. General Specification 3.1 General Specification Model Name 6223E-UUD Product Description Support WiFi/Bluetooth functionalities Dimension L x W x H: 12.2 x 13 x1.7 (typical) mm WiFi Interface Support USB2.0 BT Interface Support USB2.0 Operating temperature 0°C to 70°C Storage temperature -40°C to 85°C 3.1.2 Recommended Operating Rating Operating Temperature VCC33 FN-LINK TECHNOLOGY LIMITED 3 Min. Typ. Max. Unit 0 25 70 3.15 3.3 3.45 deg.
6223E-UUD 4. WiFi/BT RF Specification 4.1 2.4GHz RF Specification Feature Description Operating Frequency 2.400～2.4835GHz Standards WiFi: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11d, IEEE 802.11e, IEEE 802.11h, IEEE 802.11i BT: V2.1+EDR/BT v3.0/BT v3.0+HS/BT v4.2 Modulation WiFi: 802.11b: CCK(11, 5.5Mbps), QPSK(2Mbps), BPSK(1Mbps), 802.11 g/n: OFDM BT: 8DPSK, π/4 DQPSK, GFSK WiFi: 802.11b: 11,5.5,2,1 Mbps 802.11g: 54,48,36,24,18,12,9,6 Mbps 802.
6223E-UUD 802.11n /13.5Mbps : EVM≦-5dB 802.11n /135Mbps : EVM≦-28dB 802.11b@8% PER 1Mbps ≦-91dBm 2Mbps ≦ -89dBm 5.5Mbps ≦ -87dBm 11Mbps ≦ -85dBm Max input level≥-8 802.11g@10% PER 6Mbps ≦ -87dBm 9Mbps ≦ -86dBm 12Mbps ≦ -84dBm 18Mbps ≦ -82dBm Receiver Sensitivity (WiFi) 24Mbps 36Mbps 48Mbps 54Mbps ≦ ≦ ≦ ≦ -79dBm -75dBm -71dBm -70dBm Max input level≥-20 802.
6223E-UUD Media Access Control WiFi: CSMA/CA with ACK BT: AFH, Time Division Antenna External Antenna WiFi: Ad-hoc mode (Peer-to-Peer ) Infrastructure mode Software AP WiFi Direct Network Architecture BT: Pico Net, Scatter Net WiFi: WPA, WPA-PSK, WPA2, WPA2-PSK, WEP 64bit & 128bit, IEEE 802.11x, IEEE 802.11i Security BT: Simple Paring OS Supported Host Interface Android /Linux/ Win CE /iOS /XP/WIN7 WiFi: USB BT: USB Operating Voltage 3.3±10% Vdc I/O supply voltage Dimension Typical L12.0*W12.
6223E-UUD 6. Pin Assignments 6.1 Pin Outline < TOP VIEW > 6.2 Pin Definition NO Name Type Description 1 GND － Ground connections 2 ANT 0 I/O 3 ANT1 I/O WiFi RF I/O only for dual antenna 4 GND － Ground connections 5 PCM_IN I PCM data in 6 PCM_OUT O PCM data output 7 PCM_SYNC I/O PCM sync signal 8 PCM_CLK I/O PCM clock 9 BT_WAKE_HOST O Bluetooth device wake up host 10 HOST_WAKE_BT I Host wake up Bluetooth device 11 VDD33 － Main power voltage source input 3.
6223E-UUD 12 USB_DM I/O USB2.0 differential pair for WLAN And Bluetooth 13 USB_DP I/O USB2.
6223E-UUD 7. Dimensions 7.
6223E-UUD 7.
6223E-UUD 7.
6223E-UUD 8. Reference Design 9. Recommended Reflow Profile Referred to IPC/JEDEC standard.
6223E-UUD 10. Package Information the take-up package Using self-adhesive tape Size of black tape:24mm*32.6m the cover tape :2.13mmm*32.
6223E-UUD The packing case size: 350*210*370mm FN-LINK TECHNOLOGY LIMITED 14 Proprietary & Confidential Information
FCC Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
IMPORTANT NOTE: This device is intended only for OEM integrators under the following conditions: (1) According to FCC Part 15 Subpart C Section 15.212, the radio elements of the modular transmitter must have their own shielding. However, due to there is no shielding for this WIFI/BT module, this module is granted as a Limited Modular Approval. This module has been designed to operate with a PIFA antenna having a maximum gain of 2.99dBi.
