4 CHANNEL RADIO CONTROL SYSTEM INSTRUCTION MANUAL MODEL:FS- T4B Digital propotional radio control system Http:www. flyskychina. com Copy right 2007@ flysky co.
Notes Model: FS-T4B 2.4G 4 Channel remote system Menu 1.Introduction..................................2 2.Services.....................................2 3.The special symbols...........................3 4.safty guides..................................3 5.Power charging...............................4 6.Transmitter parameters.........................5 7.Receiver parameters...........................5 8.Each part of the transmitter....... ...............6 9.Receiver and server connectivity.................
Notes Model: FS-T4B 2.4G 4 Channel remote system 1.Introduction Thank you for choosing 2.4 G ratio remote control digital products, if you are the first time to use this type of products, please read this statement carefully and strictly in accordance with the requirements of operation. You could refer to the Manual if you meet any problems during the operation . Please well keep the manual after use because you might have to use it again next time.
Notes Model: FS-T4B 2.4G 4 Channel remote system 3.The special symbols Please pay attention to the following symbols when it appear on the manual, and read carefully. If the oper at or does not oper at e by fol low ing the inst ruct ions, Danger:the oper at or may lead to ser ious inj ur ies, even Mor tal dang er. If the operator does not operate by following the instructions, Warning: the operator may lead to serious injuries, even Mortal danger.
Notes Model: FS-T4B 2.4G 4 Channel remote system 5.Battery charging notes If your transmitter, receiver using a nickel-cadmium, nickel-metal hydride rechargeable battery, you have to well-check before you fly. If lack of electricity, it could happen those phenomenon like inadequate control or out of control, resulting accident. So please charge immediately when low in battery. If you are using a nickel-cadmium, nickel-metal hydride batteries for recharging, please use our company dedicated charger.
Notes Model: FS-T4B 2.4G 4 Channel remote system 6.Transmitter parameters *Channels：１６ *Charger port: yes *Frequency band: 2.4GHz *Simulator port: PS- 2 *Power resource：1.5V*8 "AA"Battery *Program type: GFSK *Modulation type:FM *RF power：1 9 d b *Static current： ≤250mA *Voltage display type：LED *Size：189*97*218mm *Weigth: 575g *Color: black *Antenna length：26mm 7.Receiver parameters *Channel：16 *Frequency band: 2.4GHz *Power resource：1.
Notes Model: FS-T4B 2.4G 4 Channel remote system 8.
Notes Model: FS-T4B 2.4G 4 Channel remote system 9.Receiver and server connectivity CH1 Ch2 Ch3 Ch4 Battery Main receiver Receiver Module When installing the receiver please make sure that two items showed 90 degree angle.
