The code for the distribution is allocated automatically when

it is created, leave this unchanged. However, this can be

changed if needed.The code must be a three-digit number bet-

ween 1 and 99.

The purpose of the code for the distribution is that measure-

ments in the test instrument can be stored so that they can be

assigned automatically to the associated distributions and cur-

rent circuits on reading.The code for the distribution is the num-

ber that is entered for the distribution on storing at the test in-

strument and under which the measurements are stored in the

test instrument.

In the Fluke installation tester 1653 the data record field is

used as distribution code.

In addition a number (No.) can be stated for the distribution,

leave this field empty. If a name is entered here, this is printed

out instead of the distribution code.

3) Select as name for the distribution "Meter cabinet with distribu-

tion field". To do this click on the field "6" on the right next to the

input field and a list of all used distribution names appears. Se-

lect the corresponding entry from the list

For the automatic assignment the measurements to the distri-

butions and current circuits the distribution code within a test

must be unequivocal, no duplicate numbers may occur. The

distribution code is allocated automatically when it is created,

leave this field unchanged.However, the code can be changed

if needed.

If duplicate distribution codes exist within a customer, you are

informed about this directly by a corresponding message.

These must then be changed in the Distribution window cor-

respondingly.
