3) Complete the "Order No." fields (e.g. with 2004-05) and

"Remark" as required.

4) All further marking fields and input windows can be marked and

completed as required..

A test report number is entered automatically in the "Test re-

port No." field. For this purpose Fluke DMS 0100/INST sear-

ches in all customers for the last allocated number and enters

the next free number in this field. However, this suggested test

report number can be changed at any time.

Completion of the "Visual check, Checked,

E-Check*-report" register windows

In these register windows you can mark and complete the mar-

king fields and input windows as required corresponding to the

performed tests.

Completion of the "Measurement" register

window

In this register window the two marking fields and the "Insula-

tion resistance between bus conductors" input field can be

used for evidence of the described tests.

This register window has two additional "Earth resistance" und

"Used measuring and test instruments" fields. These two fields

have the following properties:

In the "Earth resistance" field the highest measured earth re-

sistance for all associated distributions and current circuits is

entered on reading measurements.This value can be changed

at any time.

This value can originate from a direct earth measurement or from a

RCD contact voltage measurement. If the measurements are

changed subsequently in the associated tables under "distribution

current circuit measurements", then this value is not updated.

• E-Check is a protected term of the Landesinnungsverband

Bayern.

Quick Reference Guide

Example for Fluke DMS 0100/INST
