Digital Communication Interface
Command Description
Command
Format
Command
Example Returned
Returned
Example
Acceptable
Values
Set serial linefeed mode to
on
lf[eed]=on lf=on
Set serial linefeed mode to
off
lf[eed]=of[f] lf=of
Calibration Menu
Read R0 calibration
parameter
r[0] r r0: 999.999 r0: 100.578
Set R0 calibration parame
-
ter to n
r[0]=n r=100.324 90 to 110
Read ALPHA calibration
parameter
al[pha] al al: 9.9999999 al:
0.0038573
Set ALPHA calibration pa
-
rameter to n
al[pha]=n al=0.003843
3
.002 to .005
Read DELTA calibration
parameter
de[lta] de de:9.99999 de: 1.507
Set DELTA calibration
parameter
de[lta]=n de=1.3742 0–3.0
Read BETA calibration
parameter
be[ta] be be:9.999 be:0.342
Set BETA calibration
parameter
be[ta]=n be=0.342 –100.0 to
100.0
Functions not on menu
Read firmware version
number
*ver[sion] *ver ver.9999,9.99 ver.9133,1.0
0
Read structure of all
commands
h[elp] h list of commands
Read all operating
parameters
all all list of parameters
Legend: [] Optional Command data
{} Returns either information
n Numeric data supplied by user
9 Numeric data returned to user
x Character data returned to user
Note: WhenDUPLEXissettoFULLandacommand is sent to READ, the command is re
-
turned followed by a carriage return and linefeed. Then the value is returned as indi
-
cated in the RETURNED column.
Controller Communications Commands continued
