User manual

100.0 C Well temperature in degrees Celsius
S
Access set-point memory
1 100. Set-point memory 1, 100°C currently used
To change the set-point memory to another preset value press the “UP” or
“DOWN” button.
4 150 New set-point memory 4, 150°C
Press the “SET” button to display the new selection and access the set-point
value.
S
Accept selected set-point memory
7.2.2 Set-point Value
The set-point value may be adjusted after selecting the set-point memory
and pressing the “SET” button. The set-point value is displayed with the
units, C or F, at the left.
4 120. Set-point value 4, 120.0°C
If the set-point value does not need to be changed, press the “EXIT” button
to resume displaying the instrument temperature. Press the “UP” or the
“DOWN” button to adjust the set-point value.
U
Increment display
125.0 New set-point value
When the desired set-point value is reached press the “SET” button to ac
-
cept the new value. If the “EXIT” button is pressed, any changes made to
the set-point are ignored.
S
Accept new set-point value
7.3 Temperature Scale Units
The temperature scale units of the controller can be set by the user to de
-
grees Celsius (°C) or Fahrenheit (°F). The units are used in displaying the
well temperature, set-point, and proportional band.
Press the “SET” button after adjusting the set-point value to change display
units
21
7
Controller Operation
