User manual
Table Of Contents
- Table of Contents
- 1 Before You Start 1
- 2 Introduction 7
- 3 Specifications and Environment Conditions 9
- 4 Quick Start 13
- 5 Parts and Controls 15
- 6 General Operation 17
- 7 Controller Operation 19
- 7.1 Target Temperature 19
- 7.2 Temperature Set-point 19
- 7.3 Temperature Scale Units 21
- 7.4 Scan 22
- 7.5 Set-point Resistance 23
- 7.6 Temperature Scale Units 23
- 7.7 Secondary Menu 23
- 7.8 Heater Power 23
- 7.9 Proportional Band 24
- 7.10 Controller Configuration 25
- 7.11 Operating Parameters 25
- 7.12 Serial Interface Parameters 26
- 7.13 Calibration Parameters 27
- 8 Digital Communication Interface 29
- 9 Calibration Procedure 35
- 10 Maintenance 39
- 11 Troubleshooting 41
- Figures
- Tables
3 Specifications and Environment
Conditions
3.1 Specifications
Temperature
Range
†
–30°C to 150°C (-22°F to 302°F)
Accuracy
‡
±0.4°C (±0.72°F) [using 1/8" PRT]
Stability ±0.1°C (±0.18°F)
Target Size 2.25" (57 mm)
Target Emissivity
0.95 (±0.02 from 8 to 14μM)
Resolution 0.1° C or F
Heating Time 15 minutes (25°C to 150°C)
Cooling Time 15 minutes (25°C to -20°C)
Power 115 VAC (±10%), 1.5 A, or 230 VAC (±10%), 1.0 A, switchable,
50/60 Hz
Size (H,W,D) 152 x 286 x 267 mm (6 x 11.25 x 10.5")
Weight 4.6 kg (10 lb.)
Safety OVERVOLTAGE (Installation) CATEGORY II, Pollution Degree 2 per
IEC1010-1
†
When using a purge, the high and low range are reduced. This amount depends on the
flow and temperature of the purge.
‡
Temperature difference between the IR target surface and the reference probe are cal
-
culated as shown in the graph in Figure 1 on page 10. Note: As the temperature of the
IR target surface increases, the temperature difference decreases.
9
3
Specifications and Environment Conditions
