Mounting, installation, adjustment
26
5113196-2
5.3.1
Slide rail cutting, RFID
Slide rail cutting to
clear RFID when placed between
two paralle
l conveyors
at C-C 60 mm. See picture below
.
5112695
64
Cut to here
A
A
A-A
5112695
2.
1.
1
...
...
