User and installation manual

MODEL: PV7D (SHORT FORM)
7A 12V HIGH EFFECINECY DUAL BATTERY CHARGE CONTROLLER
SES Flexcharge USA, 1217 State St, Charlevoix, MI 49720
www.flexcharge.com Phone [phone] Fax [phone]
PV7 Installation Diagram
NOTE: You must solder all
wire to wire connections.
See our web site at
www.flexcharge.com for
com
p
lete instructions
If only one battery bank use the
RED wire only. Or connect
RED and YELLOW to
g
ethe
r
