User Manual

FACP Activations Appendix B: MS-9200
ACM-8RF PN 50362:C 03/21/01
33
Alarm and Trouble Activation
Table 11 provides the switch settings for ACM-8RF DIP switch SW3 when
configuring the relays to trigger for MS-9200 alarm and trouble activation. A
maximum of 16 ACM-8RFs are required if relays are to be designated to trigger
on any FACP status change. If system status relays are not required, 14 ACM-
8RFs may be used to allow individual relay triggering for alarm and trouble
activation of FACP zones 1 through 56. When using 14 ACM-8RFs, be sure
to use the switch settings for the 3rd through the 16th ACM-8RF in Table 11.
When the MS-9200 is programmed for an annunciator without a UDACT-F,
the first 16 relays will be assigned to the status functions listed in the table
below.
If the MS-9200 is programmed for an annunciator and
a UDACT-F, the first
16 relays will be assigned to the status functions listed in Table 12 on page 35.
MS-9200
Zone
ACM-8RF
Alarm
ACM-8RF
Trouble
Switch Settings
System Status 1=System Alarm 5=System Trouble
1st ACM-8RF
SW3-1 = ON;
SW3-5 = ON
All other SW3s = OFF
System Status Relay 2 (not used) 6=Alarm Silence
System Status Relay 3 (not used) Relay 7 (not used)
System Status Relay 4 (not used) Relay 8 (not used)
System Status Relay 1 (not used) 5= Supervisory
2nd ACM-8RF
SW3-2 = ON;
SW3-5 = ON
All other SW3s = OFF
System Status Relay 2 (not used) Relay 6 (not used)
System Status Relay 3 (not used) Relay 7 (not used)
System Status Relay 4 (not used) 8= Panel Trouble
Z1 Relay 1 Relay 5
3rd ACM-8RF
SW3-3 = ON;
SW3-5 = ON
All other SW3s = OFF
Z2 Relay 2 Relay 6
Z3 Relay 3 Relay 7
Z4 Relay 4 Relay 8
Z5 Relay 1 Relay 5
4th ACM-8RF
SW3-4 = ON;
SW3-5 = ON
All other SW3s = OFF
Z6 Relay 2 Relay 6
Z7 Relay 3 Relay 7
Z8 Relay 4 Relay 8
Z9 Relay 1 Relay 5
5th ACM-8RF
SW3-1 = ON;
SW3-6 = ON
All other SW3s = OFF
Z10 Relay 2 Relay 6
Z11 Relay 3 Relay 7
Z12 Relay 4 Relay 8
Z13 Relay 1 Relay 5
6th ACM-8RF
SW3-2 = ON;
SW3-6 = ON
All other SW3s = OFF
Z14 Relay 2 Relay 6
Z15 Relay 3 Relay 7
Z16 Relay 4 Relay 8
Z17 Relay 1 Relay 5
7th ACM-8RF
SW3-3 = ON;
SW3-6 = ON
All other SW3s = OFF
Z18 Relay 2 Relay 6
Z19 Relay 3 Relay 7
Z20 Relay 4 Relay 8
Table 11 SW3 Settings for Alarm and Trouble
