CONNECTION THROUGH ETHERNET

HARDWARE

CONNECTION THROUGH ETHERNET

SUGGESTIONS & SOLUTIONS FOR HARDWARE

Summary of content (4 pages)

PAGE 1
CONNECTION THROUGH ETHERNET HARDWARE CONNECTION THROUGH ETHERNET SUGGESTIONS & SOLUTIONS FOR HARDWARE Copyright Copyright 2006 2006 by by FingerTec FingerTec Worldwide Worldwide Ltd. Ltd. All All rights rights reserved. reserved.
PAGE 2
CONNECTION THROUGH ETHERNET 1. Make sure the communication settings in the reader are configured as below. To enter communication settings follow the steps below: MENU > OPTION > COMM OPT Baud Rate Dev Num IP Add Net Speed Ethernet RS232 RS485 Comm Key 2. 115200 1 192.168.1.201 10M-F Y N N 0 The IP address set in the reader must be the same as set in software. Example: In WAC 101 In TCMS v2 software 192.168.1.201 192.168.1.
PAGE 3
CONNECTION THROUGH ETHERNET For Windows XP user, they are advised to assign a specific IP address for computer in used before using the “ping” command. If no IP has been assigned. The device will not reply to the ping command and instead “unreachable destination” will be shown on the screen. Assign an IP address for computer if Windows XP is used. 3. You may now launch TCMS v2.1.0 software by double-clicking TCMS v2 icon. Look for the option “Finger Biometric Settings”.
PAGE 4
CONNECTION THROUGH ETHERNET Take note on the followings: • Make sure the column “Disabled” is unchecked. • Make sure your product key and activation code are the same as on software installation CD. • ID number of device is the same as in the column “ID”. • Select the TCP/IP in the column “Connection”. • Ignore Baud rate when you are using TCP/IP as connection. • IP address of device is the same as displayed in the column “IP address”. • Always leave the column “Key” as blank.
