1. Introduction
Thank you for your purchase of the Ambient Weather WS-1285 Weather Station with time, indoor
temperature and humidity, outdoor temperature and outdoor humidity, barometer and weather
forecasting. The following user guide provides step by step instructions for installation, operation and
troubleshooting. To download the latest manual and additional troubleshooting tips, please visit:
http://ambientweather.wikispaces.com/ws1285
2. GettingStarted
The WS-1285 weather station consists of a display console (receiver), and a wireless thermometer
(remote transmitter).
2.1PartsList
QTY Item
1 Display Console
Frame Dimensions (LxWxH): 5.5 x 3.0 x 1.0 in
LCD Dimensions (LxW): 3.5 x 2.0”
1 Thermometer transmitter (WH5) with mounting bracket
Dimensions (LxWxH): 4.5” x 1.25” x 0.5”
1 User Manual
2.2RecommendTools
• Philips screwdriver (precision)
• Drill for mounting bracket
2.3RemoteThermometerSensorSetUp
Note: To avoid permanent damage, please take note of the battery polarity before inserting the
batteries.
Remove the battery door on the back of the sensor with a Philips screwdriver (there is only one screw,
in the middle of the unit). Insert two AAA batteries as shown in 错误！未找到引用源。 (we
recommend lithium batteries for cold weather climates, but alkaline batteries are sufficient for most
climates).
Replace the battery door and set screw. Note that the temperature and humidity will be displayed on
the LCD display. Looking at the back of the unit from top to bottom, the polarity is (+) (-) for the left
battery and (-) (+) for the right battery.
