TS Series,
Positive Displacement, oval gear principle
Custody Transfer accuracy,
for use on
refined fuels, LPG, heavy fuel oils, glycols, lube oils & petrochemicals
 V●● = Mechanical flow meter with mechanical register
 F●● = Electronic flow meter with ELNC, EMR³ or for other register
 W●● = Gland-less flow sensor (without display)
TS15C W04
TS20A V13 ATCBMXAH4
with high capacity strainer,
air eliminator & mechanical preset valve
TS20A V06 AL
Also available with mechanical
preset/valve and/or ticket printer
TS20A F63 AA2UAS428
Temperature compensated,
with optional solenoid valve
TM Series,
Positive Displacement, oval gear principle, 1/4” - 3/4”
Linearity: ±0.5% with 10:1 turn-down.
TM06A
with ELNC
register
TM04D with
CC56 in NEMA 4X
TN Series,
Positive Displacement, nutating disc principle.
The economical alternative with moderate accuracy.
Lower Cost of Ownership!
SIZE GP M P SI
TS10A 1"
40 150 & 400
TS15A 1½"
60 150 & 400
TS20A 2"
150 150 & 400
TS30A 3"
200+ 150 & 400
TS10C 1"
40 150 & 400
TS15C 1½"
60 150 & 400
TS20C 2"
150 150 & 400
TS30C 3"
200+ 150 & 290
316SS
Hardcoat
Anodized
Aluminum
SIZE PSI Viscosity Capacity
TN740A 1"
10 0 0 15 0 + c S t 10 G P M
TN760A 1.1/2"
400 150+ cSt 15 GPM
TN860A 1.1/2"
150 0.7-15 cSt 60 GPM
TM06D
with
CC56 in
NEMA 7/4X
SIZE GPM PSI
TM03A
Hardcoat
3/8"
31500
TM04A
Anodized
1/2"
10 15 0 0
TM06A
Aluminum
3/4"
20 1500
TM02D 1/4"
0.3 1500
TM03D 3/8"
3 1500 & 2500
TM04D 1/2"
10 1500 & 2500
TM06D 3/4"
20 1500
316SS
3 . 4
