4.2. Server Side Connection Descriptors
1
Section Title
Connections
Column Title Function Legal Values
Adapter Adapter Name Prof_DP_MS
Example
// Server Side Connections
Connections
Adapter
Prof_DP_MS
4.3. Server Side Node Descriptors
Section Title
Nodes
Column Title Function Legal Values
Node_Name Provide name for Node Up to 32 alphanumeric characters
Protocol Specify protocol used Anybus_Prof_DP_S
Example
// Server Side Nodes
Nodes
Node_Name, Protocol
Prof_5, Anybus_Prof_DP_S
Only one Server Node may be defined for each connection.
If you are interested to know when support for multiple virtual Server Nodes on a single
connection will be provided please contact the Sales Department."
1
The X30 Profibus card auto-senses the Baud rate
