Datasheet

Data subject to change without notice.
*Consult separate raw material data for more detailed information
PROPERTY ABS
Ingress Protection (EN 60529) IP 65
Impact Resistance (EN 62262) IK 07
Temperature Range Celsius -40°. . .80°C
(short term) Fahrenheit -40°. . .175°F
Temperature Range Celsius -40°. . .60°C
(continuous) Fahrenheit -40°. . .140°F
Electrical Insulation Totally insulated
Light Grey Parts Colour RAL 7035; Industry Grey
Transparent Clear PC Cover Transparent
Cover Screws Grey
Cover Screws Polyamide (PA)
Gasket PUR
Flammability rating UL 94 HB
Glow Wire Test (IEC 695-2-1) 650°C
Non-toxicity Halogen Free
Chemical Resistance * Good
CONFORMITY TO STANDARDS
Europe Empty enclosures for low-voltage switchgear and
Control Gear Assemblies EN 62208:2003 (50298:1998)
RoHS directive 2002/95/EC
Rapid hinges included.
Quick to install.
PUR gasket allows a
stable and high IP rating
Several options for
wall mounting
Several
mounting
pods for
accessories
RoHS compliant,
halogen free material
TECHNICAL INFORMATION
Multiple wall mounting
options
Sealing availability for
added security
