Datasheet

Enclosing innovations
Sample photo
120
2520
1
104.5
109.5
359
387.5
402
380
372.5
100
200
178.5
237
250.5
M6
Ø 6.5
Ø10
EURONORD P 402x250x120
EURONORD P 254012
Order symbol: P 254012 EAN: 6418074004437
Product nbr: 7094400 El. number:
Description: Enclosure Finland: 3423677
Remarks: Polyester Electric No.
Denmark:
8212005701
Electric No. Italy: 7331060
Electric No. Sweden: 2536233
Including: Base, cover with EPDM gasket and stainless steel cover screws.
Dimensions: Length Width Height
mm: 402 250 120
inch: 15.8 9.8 4.7
Materials:
Material: Polyester
Base colour: RAL 7001
Cover screws material: Stainless steel
Cover colour: RAL 7001
Gasket material: EPDM
Temperatures:
Temperature °C (short term): -50 … 120 °C
Temperature °C (continuous): -40 … 80 °C
Temperature °F (short term): -60 … 250 °F
Temperature °F (continuous): -40 … 175 °F
Rating:
Ingress Protection (EN 60529): IP66
Impact Resistance (EN 62262): IK08
Electrical insulation: Totally insulated
Halogen free (DIN/VDE 0472, Part 815): 1
UV resistance: UL 508
Flammability Rating: UL 746C 5V
Glow Wire Test (IEC 695-2-1) °C: 960
NEMA Class: NEMA 1, 4, 4X, 12, 13
© Fibox Oy, Data subject to change without notice (printed: 14.12.2015)
