User's Manual

H350 LGA Serials Module Hardware User Manual Page of
43
22
100 GND
101 GND
102 GND
103 GND
104 GND
105 GND
106 GND
107 GND
108 GND
109 GND
110 GND
H：High Voltage Level
L：Low Voltage Level
PD：Pull-Down
PU：Pull-Up
T：Tristate
OD：Open Drain
PP：Push-Pull
5 Hardware Interface
5.1 Power Interface
5.1.1 VBAT
H350 module requires a 3.3 V~ 4.2V DC power supply to provide 2A as GSM transmitter maximum
current.
