2 Introduction
2.1 Description
H350 serials are highly integrated 3G wireless communication modules, support GSM / GPRS / EDGE
and UMTS / HSDPA / HSUPA / HSPA+.
2.2 Specifications
Specifications
Bands
H350-Axx-10 H350-Bxx-10
UMTS (WCDMA/FDD):
900/2100MHz
UMTS (WCDMA/FDD): 850/1900MHz
GSM/GPRS/EDGE: 900/1800MHz GSM/GPRS/EDGE: 850/1900MHz
Data
UMTS/HSDPA/HSUPA 3GPP release 7
HSUPA 5.76Mbps (Cat 6)
HSDPA 21Mbps (Cat 14) or 7.2Mbps (Cat 8)
GSM 3GPP release 7
EDGE (E-GPRS) multi-slot class 33(296kbps DL, 236.8kbps UL)
GPRS multi-slot class 33(107kbps DL, 85.6kbps UL)
Physical
Dimension: 29.8mm x 17.8mm x 2.00mm
Interface: LGA
Weight: 2.5 grams
Environment
Operating Temperature: -30℃ ~ +85℃
Storage Temperature: -40℃ ~ +85℃
Performance
Operating
Voltage
Voltage: 3.3V ~ 4.5V Normal: 3.8V
Operating
Current (Typical
Value)
2mA (Sleep Mode)
3G Idle: 13mA
3G Talk: 500mA
2G Talk: 260mA (GSM PCL5)
Tx Power
(Typical Value)
Class 4 (2W)： 850/900 MHz, GSM
Class 1 (1W)：1800/1900 MHz, GSM
Class E2 (0.5W)： 850/900 MHz, EDGE
