3Technical data
4 Machine features
The specified illustrations appear at the beginning of
the Operating Instructions.
5Intended use
Mobile dust extractor suitable for
– Extracting dust up to 1 mg/m³ according to dust
class 'L',
–Extracting water,
– Increased loads during commercial use,
according to IEC/EN 60335-2-69.
The user is liable for improper or non-in-
tended use.
6Operation
6.1 Connecting the mobile dust extractor
The switch [1-11] serves as an on/off switch.
Switch position "0"
Appliance socket [1-2] is disconnected from the
power, mobile dust extractor is switched off.
Mobile dust extractors
Power consumption 400 - 1200 W
Maximum appliance
socket connected load
EU
CH, DK
GB 240 V/ 110 V
2400 W
1100 W
1800 W/ 500 W
Max. suction capacity (air), extractor/turbine 95 m³/h / 222 m³/h
Max. vacuum, turbine 24000 Pa
Filter surface area 5000 cm²
Suction hose D 27 mm x 3,5 m-AS
Length of the net cable 7,5 m
Sound pressure level as per EN 60704-2-1 / Uncertainty K 72 dB(A) / 3 dB
Protection category IP X4
Container capacity CTL MINI 10 l
CTL MIDI 15 l
Dimensions L x W x H CTL MINI 430 x 330 x 420 mm
CTL MIDI 430 x 330 x 470 mm
Weight CTL MINI 8,8 kg
CTL MIDI 9,1 kg
[1-1] Suction power adjuster
[1-2] Appliance socket
[1-3] SysDoc
[1-4] Handle
[1-5] Intake opening
[1-6] Angle adapter
[1-7] Hose store
[1-8] T-LOC latch for Systainers
[1-9] Dust container
[1-10] Locking clip
[1-11] Switch
[1-12] +
[1-13]
Brake
WARNING
Unauthorised voltage or frequency!
Risk of accidents
 Observe the specifications on the machine’s
name plate.
 Observe country-specific regulations.
WARNING
Risk of injury from tools starting up unexpectedly
 Before setting the switch to the "AUTO" or
"MAN" position, make sure that the connected
tool is switched off.
