Datasheet

RoHS compliant
13
±0.3
20.2
±0.3
15.9
±0.3
A
A
17.1
±0.3
C
B
20.1
±0.3
1
9.5
±0.5
L
4-40UNC-2A
G
K
2
A-A
4
3
reverse side
1:1
4-40UNC-2A
4.5
15.3
18.3
1
1.1
4.9
3
4
max. torque are 40 Ncm
Protection standard IP67, 100% checked
according to DIN EN 60529
2
4
2 FVSW - O-ring seal Elastomer red
3
2 Locking screw FVSW1/5-K1449 4-40 / Brass nickel plated
2 1 O-ring seal Elastomer red
1 1 Plastic dust cup
FWAB1-3 / PC+ABS
black
No. St. Part
Type Description/Material
Surface plating/Colour/Class
Order-No.
Shell Size / for
No. of Contacts
B
±0.1
C
±0.3
G
±0.3
K
±0.3
L
±0.3
FWAB1 1 / 9 25 40.3 31.4 18 32.6
FWAB2 2 / 15 33.3 48.5 39.7 26.3 41.3
FWAB3 3 / 25 47 62.3 53.5 40 55.1
