Touch Panel
Touch Technology 5-Wire Resistive
Touch Connector USB
Touch Panel Drivers Windows; Linux; Mac; Android
Touch Life (Contacts) 10 million in 1 location without
failure
Surface Hardness 3H
External Connectors
All-In-One cable VGA version 1x VGA
1x Video-In
1x Audio-In
1x USB-Touch
1x 8-36V DC-IN
All-In-One cable HDMI version 1x HDMI
1x USB-Touch
1x 8-36V DC-IN
Included in the Delivery
Power Supply (see Power section)
Driver DVD
Short Installation Manual
All-In-One cable (optional VGA or HDMI)
Stylus
Remote Controller
Power
Power Indicator Green LED
Power Supply 100-240V ACDC active switch-
ing; 12V DC-Out
Working Power (V) 8~36
Power Consumption (W) 24
Stand-By Consumption (W) <1
Operation / Mechanical
Operating Temperature (°C) -25 ~ +75
Humidity Range (RH) 10%-90%
Net weight (kg) 3.40
Gross weight (kg) 5.00 (incl. cartonage)
Housing material Aluminum
Housing (cm) LxWxH 37.50 x 28.70 x 4.60
Mounting VESA 100
Anti-glare LCD Panel
IP Protection Class IP65
Screen diagonal (Inch/cm): 15/38.10
Display active screen size: 30.40×22.80
Aspect ratio: 4:3
Physical resolution: 1024×768
Maximum showable resolution
(TPCs: external):
1920×1200
Colours displayed: 16.2M
Brightness (cd/m2): 1000+
Contrast: 500:1
Typical reaction time Tr/ Tf (ms): 2/6
Visual Angle horizontal/vertical
(°):
160/160
Backlight / Backlight Lifetime
(hours):
LED / 40,000
Product name 15’’ IP65 High Brightness
Touch Monitor
Article code / EAN numer FT15TMIP65HB[HDMI]
/ 6920734015214
[6920734015207]
